Product Name：RVS Chip Aluminum Electrolytic Capacitor
Series：RVS
Operating Temperature Range°C：-40~+85??C
Working Voltage Range：4~100VDC
Capacitance Range：0.1~1500uF
Load life：2000Hours
RVS Chip Aluminum Electrolytic Capacitor, Surface Mount Aluminum Electrolytic Capacitor SMD, V-Chip
??? Reflow soldering available for reflow soldering
??? Bi-polarized
??? Available for high density surface soldering
??? Life time: 85??C 2000Hours
??? Adapted to the ROHS / REACH directive
Related Voltage: 6.3V, 10V, 16V, 25V, 35V, 50V, 63V, 100V.
Related Capacitance: 1uF,2.2uF,3.3uF,4.7uF,10uF,22uF,33uF,47uF,68uF,100uF,150uF,220uF,330uF,470uF,680uF,1000uF,1500uF.
Chip/SMD Aluminum Electrolytic Capacitor Surface Mount Aluminum Electrolytic Capacitor SMD, V-Chip
